SG6000PRO PureSine RF Generator


SKU: SG6000PRO Category:


The DS Instruments SG6000PRO RF Signal Generator continues to set the industry standard in affordable ultra-compact Signal Generation. The SG6000PRO provides a pure low-harmonic signal unlike most other compact signal generators. This fully synthesized, modern fractional-N synthesis device covers upwards of 7.1GHz and down to only 20MHz. Output power is calibrated and adjustable between +17dBm and -40dB in 0.25dB steps, or continuously via the internal variable attenuator. The bright OLED display provides useful feedback for the user, and front control buttons provide a quick alternative to USB control. The PRO has phase noise approximately 25dB lower than the standard SG6000L, a much smaller minimum frequency step size, a more accurate output level attenuator, and a wider frequency range.

         Shipping Rev 9 with enhanced harmonic filtering as of 2023!

Premium RF Signal Generator Features:

  • Active harmonic filtering for a low-distortion output waveform
  • Low phase noise for sensitive applications
  • Stand-alone and USB remote operation
  • Up to 7.1GHz output frequency (Upgraded for 2023!)
  • Adjustable output power with both steps and variable tune
  • Industry-standard SCPI command support
  • Internal ultra-low phase-noise 100MHz reference
  • External 10MHz reference frequency input port (MCX)
  • Sweep trigger input port (MCX)
  • Tiny frequency step size (2Hz)
  • Front user control buttons for frequency and power levels
  • Frequency-sweeping support (list & scan)
  • Front-mounted bright OLED display
  • Simple Windows control GUI
  • Powered from standard USB-C
  • Easy to interface with all software packages (.NET, Matlab, python, android, linux…)
  • No extra drivers required for all common host systems
  • Code examples provided for automated control
  • Standard Ethernet (NEW!)

Device Technical Specifications:

  • Extended output frequency range: 20-7100MHz
  • Calibrated output frequency range: 30-6500MHz
  • Device power output range: -40 to +17 dBm (calibrated)
  • Phase noise at 6GHz: -95dBc @ 10KHz offset
  • Frequency adjustment step size: 2Hz
  • Highest harmonic level: -40dBc typical
  • Internal attenuator (digital): 64dB (250 x 0.25dB Steps)
  • Internal attenuator (variable): ~15dB (10 bit DAC)
  • Dimensions: 2.75″ x 1.25″ x 4.15″
  • Input voltage: 5V Standard USB-C
  • Output impedance: 50 Ohm
  • RF connector: premium gold 18GHz microwave SMA

SG6000PRO Common Applications:

  • Automated testing environments
  • General RF Lab use
  • Flexible LO sourcing
  • Antenna design
  • EMC Testing
  • Production verification and testing
  • Educational / university lab use
  • Aerospace / Defense Research
  • 802.11n Development / Testing
  • LTE Engineering

Signal Generator Phase Noise Data:

Time Domain Plots:

PureSine SG6000PRO Enclosure:

SG6000PRO Control Software

Additional information

Weight 1 lbs
