12GHz Phase Shifter


SKU: PS12000 Category:


The PS12000 wideband RF Phase Shifter from DS Instruments provides handheld stand-alone and remote-controlled phase shifting from 0 to 355 degrees in 5.6-degree increments. This ultra-compact USB device features a graphic display and audio feedback. Simple to use and integrate into automated test environments, the PS12000 is extremely attractive for many radar and X-band applications.

 Device Specifications:

  • Frequency Range: 8000 – 12000 MHz
  • Angle Range: 0 – 355 degrees
  • Power Input Range: < +26dBm
  • Phase Resolution: 5.625 degrees
  • Insertion Loss: 7-8dB
  • Return Loss: > 10dB
  • Bi-directional design

PS12000 Digital Phase Shifter Features:

  • Ultra compact powder-coated aluminum case
  • Audio feedback
  • Simple automated remote control interface
  • Free PC control application
  • Micro-USB powered and controlled
  • Front control buttons and OLED display
  • Premium gold 18GHz SMA ports
  • High reliability solid-state design
  • Optional Ethernet port

Typical RF Applications:

  • Antenna systems
  • Beam forming research
  • Radar applications
  • Phased-array technology
  • RF signal cancellation
  • Electronic warfare and defense
  • Satcom


mini attenuator


Windows Phase Shift Control Application:

Technical Information / Datasheet:
