18GHz Phase Shifter

$1,399

SKU: PS18000 Category:

Description

The PS18000 Ku-Band Phase Shifter from DS Instruments provides handheld stand-alone and remote-controlled phase shifting from 0 to 355 degrees in 5.6-degree increments. This compact USB device features a graphic display and audio feedback. Simple to use and integrate into automated test environments, the PS18000 is extremely attractive for many satellite-link test applications.

 Device Specifications:

  • Frequency Range: 8000 – 18000 MHz
  • Angle Range: 0 – 355 degrees
  • Max Input Power (CW): +29dBm
  • Phase Resolution: 5.625 degrees
  • Insertion Loss: 10dB typical
  • Return Loss: 9dB typical
  • Input P1dB: 25dBm
  • Input IP3: 40dBm
  • Bi-directional design

PS18000 Digital Phase Shifter Features:

  • Ultra compact powder-coated aluminum case
  • Audio feedback
  • Simple automated remote control interface
  • Micro-USB powered
  • Free PC control application
  • Micro-USB powered and controlled
  • Front control buttons and OLED display
  • Premium gold 26GHz SMA ports
  • High reliability
  • Optional Ethernet

Typical RF Applications:

  • Antenna systems
  • Phased array research and development
  • Beam forming projects
  • Electronic warfare and defense
  • Satcom systems



mini attenuator



Phase Shift Control Application:

Technical Information / Datasheet:
